QUICK COUPLERS
OKADA SE-450 Hydraulic quick coupler
Features
- 1
- Seamless steel casting rigid one-piece body
- 2
- Adjustable Safety lock pin depending on various type of excavators.
- 3
- Double Safety lock on the primary hook.
- 4
- Widely adjustable hook range.
Specifications
Unit
- Operating Weight
- Overall Length
- Overall Height
- Overall Width
- Pin Diameter
- Suitable Carrier Range
Operating Weight
[kg]
Overall Length
[mm]
Overall Height
[mm]
Overall Width
[mm]
Pin Diameter
[mm]
Suitable Carrier Range
[Ton]
SE200
Operating Weight
370
Overall Length
883
Overall Height
560
Overall Width
440
Pin Diameter
430 - 530 Ø80
Suitable Carrier Range
20 - 25
SE350
Operating Weight
650
Overall Length
1110
Overall Height
675
Overall Width
545
Pin Diameter
520 - 700 Ø90
Suitable Carrier Range
30 - 35
SE450
Operating Weight
790
Overall Length
1160
Overall Height
700
Overall Width
620
Pin Diameter
560 - 710 Ø100
Suitable Carrier Range
40 - 50
SE850
Operating Weight
1580
Overall Length
1450
Overall Height
885
Overall Width
700
Pin Diameter
630 - 790 Ø130
Suitable Carrier Range
85 - 100
SE2000
Operating Weight
2500
Overall Length
1630
Overall Height
995
Overall Width
820
Pin Diameter
665 - 840 Ø150
Suitable Carrier Range
150 - 200
(Note) The above specificatons are subject to change without notce.
